| Mã sản phẩm | : GTX-1530F | |
| Bảo hành | : 12 tháng | |
| Lượt xem | : 1802 | |
| Giá | : Liên hệ | |
ĐỂ BIẾT THÊM CHI TIẾT VÀ GIÁ SẢN PHẨM VUI LÒNG GỌI:
Hotline: 0988 429 477 - 0985 006 115 Mr Tùng
Fiber laser cutting machine is the application of laser wavelength of 1064nm with pulse laser beam expanding, after reflection, focused radiation surface processing, surface heat through heat transfer oriented internal diffusion, theprecise digital control width, laser pulse energy, peak power and repetition rateand other parameters, the vaporization, melting, forming and cutting gap, to realize the cutting of laser processed piece.Second, the main technical indicators of GTX-1325F/1530F laser cutting machine
|
Laser wavelength |
1070nm |
|
Laser output maximum average power |
1000W |
|
Laser repetition frequency |
CW |
|
Energy instability |
≤2% |
|
Minimum cutting width |
0.2mm (material less than 0.4mm) |
|
Maximum cutting speed |
≤10m/min (Depending on the material) |
|
Maximum cutting thickness |
≤10mm (carbon steel); ≤5mm (stainless steel, galvanized sheet) |
|
Continuous working time |
≥20 hours |
|
Maximum cutting width |
1300mm×2500mm/1500*3000mm |
|
Workbench mechanical accuracy |
±0.1mm |
|
Repeatability |
±0.1mm |
|
powered by |
Three-phase five-wire AC 380V ± 5%, 50Hz ± 1% (can be changed to 220V) |
|
software |
Software has optional cutting function |
|
Equipment weight (estimate) |
3200kg/3500kg |
