Product Features
● Machine frame is heaviest welded con striation, stess released by annealing process,this has minimized deflection of the frame
● Y Axis full closed loop control
● Proportional hydraulic compensation system to prevent deformation German HEIDENHAIN linear encoder
● Taiwan HIWIN ball screw and linear guide rail，high performance AC Japanese Yaskawa AC servo motors and drives
● Rich functions CYBELEC/DELEM professional control system Electro-hydraulic servo synchronization module and pressure module
● +-0.01 mm repeat accuracies
● +-0.01 mm parallelism accuracies
Applicable industry
Stainless steel plate, iron plate, copper plate, aluminum plate and so on
Applicable Materials
Mainly applicable to non-contact cutting,hollowing and punching of carbon steel, stainless steel, galvanized sheet, thin aluminum and copper etc.
Optional Accessories
Premium Backgauge-R, Z1 -Z2, X Axis as Options Supreme Backgauge 6 axis X1/X2, R1/R2, Z1/Z2
Light Curtains or Laser Safe
Laser Check bend angle measuring device
Robotic Bending
Technical Data
| Model No. |
Nominal Pressure (kn) |
Distance Between uprights (mm) |
Length of Table (mm) |
Thorat Depthmm) |
RAM Sroke (mm) |
Speed (Times /min) |
Max.RAM Open Height (mm) |
Main Motor (kw) |
Net. Weight (kg) |
Overal Dimension L*W*H(mm) |
| HS-4015 | 400 | 1500 | 1140 | 300 | 600 | >10 | 400 | 4 | 3800 | 1700*1600*2350 |
| HS-8025 | 800 | 2500 | 2010 | 350 | 160 | >8 | 400 | 7.5 | 7500 | 2700*1650*2360 |
| HS-10032 | 1000 | 3200 | 2700 | 350 | 200 | >8 | 400 | 7.5 | 9300 | 3500*1650*2630 |
| HS-16032 | 1600 | 3200 | 2700 | 350 | 200 | >9 | 400 | 15 | 12000 | 3500*1650*2630 |
| HS-16040 | 1600 | 4000 | 3500 | 350 | 200 | >9 | 400 | 15 | 14000 | 4200*1650*2630 |
| HS-20032 | 2000 | 3200 | 2700 | 400 | 240 | >9.5 | 450 | 15 | 13000 | 3500*1900*2750 |
| HS-20040 | 2000 | 4000 | 3500 | 400 | 240 | >9.5 | 450 | 15 | 15000 | 4200*1900*2750 |
| HS-25032 | 2500 | 3200 | 2700 | 400 | 240 | >9.5 | 520 | 18.5 | 15000 | 3500*1900*2750 |
| HS-25040 | 2500 | 4000 | 3500 | 400 | 240 | >9.5 | 520 | 18.5 | 17500 | 4200*1900*2750 |
