| Mã sản phẩm | : Leeye-X9 | |
| Lượt xem | : 3338 | |
| Giá | : Liên hệ | |
ĐỂ BIẾT THÊM CHI TIẾT VÀ GIÁ SẢN PHẨM VUI LÒNG GỌI:
Hotline: 0988 429 477 - 0985 006 115 Mr Tùng
Leeye-X9 Auto cutter is designed for cutting synthetic materials, equipped with an ultra-precise cutting head that cuts the perfect care interior and seat components and minimizes the cost of every cutting piece. and increasing the number of layers that can be cut, the cutting capacity of Leeye-X9 cutting machine is 20% higher than the existing products on the market.
The new solution can reduce the parting gaps, which can improve fabric utilization to the save hundred thousand of dollars per cutting line per year.
|
Model.NO |
Leeye-X9 |
|
Cutting area (W*L) |
1700 x2500mm |
|
Machine Dimensions (mm) |
5050X2750X1500mm |
|
Weight |
2500kg |
|
Max cutting thickness |
90mm (After compressed) |
|
Max cutting speed |
80m/min |
|
Cutting accuracy |
≤±0.5mm |
|
Power |
16-25kw |
|
Cutting style |
Straight Knife Continuous Up-down Cutting (上下交替震动到切割) |
|
Cooling system |
Auto air cooling system |
|
Controller system |
KP-ACS Copyright system which compatibility with any kind of cloth CAD software |
|
Software |
Multi-language ACS software, switch freely |
|
sharpen way |
double gear derogatory method |
|
air pressure supply |
0.55Mpa 160L/Min |
|
Cutting materials |
Denim, Garment cloth(knitted and woven), plush toys, shoes, leather, care seat, sofa, medical gauze, composite fabric. |
|
Max speed of blade working |
6000rpm/min-9000rpm/min |
|
Motor & driver |
Japan Panasonic servo motors & drivers |
|
Machine power |
AC380V/50HZ |
